1 Provläsningsexemplar / Preview SVENSK STANDARD SS-EN 1746 Handläggande organ Fastställd Utgåva Sida SVENSK MATERIAL- & MEKANSTANDARD, SMS (1+9+9) Copyright SIS. Reproduction in any form without permission is prohibited. Safety of machinery Guidance for the drafting of the noise clauses of safety standards Maskinsäkerhet Riktlinjer för utformning av bulleravsnitt i säkerhetsstandarder The European Standard has the status of a Swedish Standard The European Standard was approved and published as SS-EN 1746 in English. This document contains a bilingual version that supersedes the English version. Swedish Standards corresponding to documents referred to in this Standard are listed in Catalogue of Swedish Standards, issued by SIS. The Catalogue lists, with reference number and year of Swedish approval, International and European Standards approved as Swedish Standards as well as other Swedish Standards. Europastandarden gäller som svensk standard. Europastandarden fastställdes som SS-EN 1746 och har utgivits i engelsk version. Detta dokument, som ersätter det tidigare, återger i två språkig version. Motsvarigheten och aktualiteten i svensk standard till de publikationer som omnämns i denna standard framgår av Katalog över svensk standard, som ges ut av SIS. I katalogen redovisas internationella och europeiska standarder som fastställts som svenska standarder och övriga gällande svenska standarder. ICS Standarder kan beställas hos SIS Förlag AB som även lämnar allmänna upplysningar om svensk och utländsk standard. Postadress: SIS, Box 6455, STOCKHOLM Telefon: Telefax: E-post: sis.sales@sis.se. Internet: Upplysningar om sakinnehållet i standarden lämnas av SMS. Telefon: Telefax: E-post: info@sms-standard.se Prisgrupp Q Tryckt i juli 2000

2 Provläsningsexemplar / Preview EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM EN 1746 September 1998 ICS Descriptors: safety of machine, accident prevention, acoustics, noise: sound, engine niose, standards, specifications, technical writing, standard plans English version Safety of machinery Guidance for the drafting of the noise clauses of safety standards Sécurité des machines Guide relatif à la rédaction des articles bruit des normes de sécurité Sicherheit von Maschinen Anleitung für die Abfassung der Abschnitte über Geräusche in Sicherheitsnormen This European Standard was approved by CEN on 21 December CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the Central Secretariat or to any CEN member. This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the Central Secretariat has the same status as the official versions. CEN members are the national standards bodies of Austria, Belgium, Czech Republic, Denmark, Finland, France, Germany, Greece, Iceland, Ireland, Italy, Luxembourg, Netherlands, Norway, Portugal, Spain, Sweden, Switzerland and United Kingdom. CEN European Committee for Standardization Comité Européen de Normalisation Europäisches Komitee für Normung Central Secretariat: rue de Stassart 36, B-1050 BRUSSELS 1998 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members Ref. No. E

3 EUROPASTANDARD EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM Provläsningsexemplar / Preview EN 1746 September 1998 ICS Nyckelord: maskinsäkerhet, akustik, buller, maskinbuller, standard, teknisk beskrivning, standard skrivning Svensk version Maskinsäkerhet Riktlinjer för utformning av bulleravsnitt i säkerhetsstandarder Sécurité des machines Guide relatif á la rédaction des articles bruit des normes de sécurité Safety of machinery Guidance for the drafting of the noise clause of the safety standards Sicherheit von Maschinen Anleitung fur die Abfassung der Abscnitte uber Geräusche in Sicherhetinormen Denna standard är den officiella svenska versionen av. För översättningen svarar SIS. Denna europastandard antogs av CEN CEN-medlemmarna är förpliktade att följa fordringarna i CEN/CENELECs interna bestämmelser som anger på vilka villkor denna europastandard i oförändrat skick skall ges status som nationell standard. Aktuella förteckningar och bibliografiska referenser rörande sådana nationella standarder kan på begäran erhållas från CENs centralsekretariat eller från någon av CENs medlemmar. Denna europastandard finns i tre officiella versioner (engelsk, fransk och tysk). En version på något annat språk, översatt under ansvar av en CEN-medlem till sitt eget språk och anmäld till CENs centralsekretariat, har samma status som de officiella versionerna. CENs medlemmar är de nationella standardiseringsorganen i Belgien, Danmark, Finland, Frankrike, Grekland, Irland, Island, Italien, Luxemburg, Nederländerna, Norge, Portugal, Schweiz, Spanien, Storbritannien, Sverige, Tjeckien, Tyskland och Österrike. CEN European Committee for Standardization Comité Européen de Normalisation Europäisches Komitee für Normung Central Secretariat: rue de Stassart 36, B-1050 BRUSSELS 1998 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members Ref. Nr. Sv

4 Page 2 Provläsningsexemplar / Preview Contents Foreword... 2 Introduction Scope Normative references Requirements for drafting the noise clauses of type C-Standards General drafting rules Clause on "noise as a hazard" Clause on "noise reduction as a safety requirement" Noise reduction at source by design Noise reduction by protective devices Noise control by information Clause on "verification of compliance with the safety requirements and measures" Verification based on noise emission values Verification of noise reduction Clause on "instruction handbook"... 7 Annex A (informative) Further guidance on the evaluation of noise emission data... 8 Annex B (informative) Bibliography... 9 Foreword This European Standard has been prepared by Technical Committee CEN/TC 211 Acoustics, the secretariat of which is held by DS. This European Standard shall be given the status of a national standard, either by publication of an identical text or by endorsement, at the latest by March 1999 and conflicting national standards shall be withdrawn at the latest by March This European Standard has been prepared by Technical Committee CEN/TC 211 "Acoustics", the Secretariat of which is held by Denmark, as a guidance document to be used by CEN machinery Technical Committees as the basis for the preparation of the clauses concerning noise in their type C-Standards. "Guidance" is used, because the document is a general one and therefore may not be applicable in all details for a specific type of machinery. This European Standard has been prepared under a mandate given to CEN by the European Commission and the European Free Trade Association, and supports essential requirements of EU Directive(s). Several documents concerning noise referred to in this European Standard are at the moment at the stages of draft. The latest reference document numbers are given which makes it possible to obtain these documents from a national member body. This European Standard also contains two annexes which are informative. According to the CEN/CENELEC Internal Regulations, the national standards organizations of the following countries are bound to implement this European Standard: Austria, Belgium, Czech Republic, Denmark, Finland, France, Germany, Greece, Iceland, Ireland, Italy, Luxembourg, Netherlands, Norway, Portugal, Spain, Sweden, Switzerland and the United Kingdom.

5 Provläsningsexemplar / Preview Sida 2 Innehåll Förord... 2 Inledning Omfattning Normativa hänvisningar Krav på formuleringar av bullerbestämmelser för C-standarder Allmänna formuleringsregler Paragraf om buller som en risk Paragraf om bullerminskning som säkerhetsåtgärd Bullerminskning vid källan genom konstruktion Bullerminskning genom bullerskyddsanordningar Bullerminskning genom information Paragraf om kontroll i enlighet med säkerhetskrav och åtgärder Verifikation baserad på bulleremissionsvärden Verifikation av bullerminskning Paragraf om instruktionsbok... 7 Bilaga A (informativ) Ytterligare riktlinjer för utvärdering av bulleremissionsdata... 8 Bilaga B (informativ) Litteraturförteckning... 9 Förord Denna europastandard har utarbetats av den tekniska kommittén CEN/TC 211 Acoustics. Sekretariatet hålls av DS. Denna europastandard har utarbetats under ett mandat som CEN fått av Europeiska kommissionen och EFTA. Den stöder grundläggande krav i EUs direktiv. Denna europastandard skall ges status som nationell standard, antingen genom att publicera en identisk text eller genom ikraftsättning senast mars 1999, och motstridande nationella standarder skall dras in senast mars Enligt CEN/CENELECs interna bestämmelser anmodas följande länder att anta denna europastandard: Belgien, Danmark, Finland, Frankrike, Grekland, Irland, Island, Italien, Luxemburg, Nederländerna, Norge, Portugal, Schweiz, Spanien, Storbritannien, Sverige, Tjeckien, Tyskland och Österrike.

6 Page 3 Provläsningsexemplar / Preview Introduction For many machines, noise is a significant hazard, i.e. a hazard which an assessment carried out in accordance with EN 1050 has lead to identify as being connected with one or more essential requirements decreed in annex I of the Machinery Directive and which requires a specific action on the part of the manufacturer or supplier (see of EN 414:1992). The information contained in this European Standard is based on the following principles: a) noise reduction is an integral part of machinery safety, and b) machinery must be so designed and constructed that risks resulting from the emission of airborne noise are reduced to the lowest level taking account of technical progress and available means of reducing noise, in particular at source, and c) specific quantitative information on airborne noise emitted by machinery under specified operating and mounting conditions shall be given in accordance with the relevant noise test code, or, if no test code exists, under specified individual conditions. d) the noise clauses of type C-Standards shall deal with noise emission aspects including residual risk; but information on how the noise immission at the work station can be further reduced, including advice on personal protection equipment, may be helpful. 1 Scope This European Standard gives guidance on how to deal with noise in type C- Standards where noise is identified as a significant hazard (see 4.5 of EN 292-1: 1991). As such, this European Standard supplements the rules given in EN 414: The exact way that noise is dealt with for a particular type of machinery will depend on the structure of the type C-Standards and is the responsibility of the type C-Standard Technical Committees. 2 Normative references This European Standard incorporates, by dated or undated reference, provisions from other publications. These normative references are cited at the appropriate places in the text and the publications are listed hereafter. For dated references, subsequent amendments to or revisions of any of these publications apply to this European Standard only when incorporated in it by amendment or revision. For undated references the latest edition of the publication referred to applies. EN 292-1:1991 Safety of machinery Basic concepts, general principles for design Part 1: Basic terminology, methodology. EN 292-2:1991/ Safety of machinery Basic concepts, general principles for A1:1995 design Part 2: Technical principles and specifications. EN 414:1992 pren ISO 3740 pren ISO 3741 Safety of machinery Rules for the drafting and presentation of safety standards. sources Guidelines for the use of basic standards (ISO/DIS 3740:1998) sources using sound pressure precision methods for reverberation chambers (ISO/DIS :1998)

7 Provläsningsexemplar / Preview Sida 3 Inledning Buller utgör en väsentlig potentiell risk vid många maskiner. En uppskattning gjord i enlighet med EN 1050 visar att en sådan risk kan kopplas samman med ett eller flera av de grundläggande kraven i annex 1 i Maskindirektivet, som kräver specifika åtgärder från tillverkarens eller leverantörens sida (se i EN 414:1992). Informationen i denna Europastandard baseras på följande principer: a) bullerbekämpning är en nödvändig del i maskinsäkerhetsarbetet; b) maskiner måste vara utformade och konstruerade så att risker som härrör från emissionen av luftburet buller är minskat till en lägsta nivå med hänsyn tagen till tekniska framsteg och till tillgängliga hjälpmedel för att reducera buller, speciellt vid källan; c) exakt information om det som erhålles under noggrant angivna drifts- och uppställningsförhållanden skall ges i enlighet med den produktspecifika bullermätmetoden, eller om ingen sådan mätmetod skulle finnas, skall de under rådande omständigheterna vid mätningen anges; d) paragraferna som behandlar buller i C-standarder skall innehålla bulleremissionsaspekter inklusive kvarvarande risk, men också information, om hur bullerimmission vid arbetsplatsen kan minskas ytterligare, kan vara till hjälp, inklusive råd om personlig skyddsutrustning. 1 Omfattning Denna Europastandard ger riktlinjer för hur buller ska behandlas i C-standarder där buller uppfattas som en betydande risk (se 4.5 i EN 292-1:1992). Denna standard fungerar som ett tillägg till reglerna i EN 414:1992. Det sätt på vilket buller behandlas vid en speciell maskintyp, beror på strukturen hos C-standarden och ansvaret ligger hos de tekniska kommittéerna för respektive C-standard 2 Normativa hänvisningar Denna standard innehåller daterade eller odaterade hänvisningar till regler i andra publikationer. Dessa normativa hänvisningar återfinns i den löpande texten. Publikationerna anges nedan. Beträffande daterade hänvisningar till publikationer som senare har ändrats eller fått tillägg, gäller dessa ändringar eller tillägg endast då de har införts i denna standard. Vid odaterade hänvisningar gäller den senaste utgåvan av publikationen. EN 292-1:1991 Safety of machinery Basic concepts, general principles for design Part 1:Basic terminology, methodology. EN 292-2:1991/ Safety of machinery Basic concepts, general priciples for design Part 2: Technicalprinciples and specifications EN 414:1992 safety of machinery Rules for the drafting and presentation of safety standards, EN ISO 3740 sources Guidelins for the use of basic standrads (ISO/DIS 3740:1998) EN ISO 3741 sources using sound pressure prescision methods for reverberation of chambers (ISO/DIS :1998)

8 Page 4 Provläsningsexemplar / Preview EN ISO EN ISO EN ISO 3744 EN ISO 3746 pren ISO 3747 EN ISO 4871 EN ISO EN ISO Determination of sound power levels of noise sources Engineering methods for small, movable sources in reverberant fields. Part 1: Comparison method in hard-walled test rooms (ISO :1994) sources Engineering methods for small, movable sources in reverberant fields. Part 2: Methods for special reverberation test rooms (ISO :1994) sources using sound pressure Engineering method in an essentially free field over a reflecting plane (ISO 3744:1994) sources using sound pressure Survey method using an enveloping measurement surface over a reflecting plane (ISO 3746:1995) sources using sound pressure Comparison method for use in situ (ISO/DIS 3747:1998) Acoustics Declaration and verification of noise emission values of machinery and equipment (ISO 4871:1996) sources using sound intensity Part 1: Measurement at discrete points (ISO :1993) sources using sound intensity Part 2: Scanning method (ISO :1996) EN ISO Acoustics Noise emitted by machinery and equipment Guidelines for the use of basic standards for the determination of emission sound pressure levels at the work station and at other specified positions (ISO 11200:1995) EN ISO Acoustics Noise emitted by machinery and equipment Measurement of emission sound pressure levels at the work station and at other specified positions Engineering method in an essentially free field over a reflecting plane (ISO 11201: 1995) EN ISO Acoustics Noise emitted by machinery and equipment Measurement of emission sound pressure levels at the work station and at other specified positions Survey method in situ (ISO 11202:1995) EN ISO Acoustics Noise emitted by machinery and equipment Determination of emission sound pressure levels at the work station and at other specified positions from the sound power level (ISO 11203:1995) EN ISO Acoustics Noise emitted by machinery and equipment Measurement of emission sound pressure levels at the work station and at other specified positions Method requiring environmental corrections (ISO 11204:1995) EN ISO/ Acoustics Recommended practice for the design of low-noise TR machinery and equipment. Part 1: Planning (ISO/TR : 1995) EN ISO Acoustics Procedure for the comparison of noise emission data for machinery and equipment (ISO 11689:1996)
