1 PEA - Printed Electronics Arena PEA Printed Electronics Arena Funded by:

PEA - Printed Electronics Arena Svenska företag inom Tryckt elektronik Svenska aktörer inom tryckt elektronik Printed Electronics Arena LunaLec (Umeå) Sensible Solutions (Sundsvall) Mevia

2 PEA - Printed Electronics Arena Svenska företag inom Tryckt elektronik Svenska aktörer inom tryckt elektronik Printed Electronics Arena LunaLec (Umeå) Sensible Solutions (Sundsvall) Mevia (Göteborg) OTS (Järfälla) Thin Film Electronics (Linköping) Invisense (Norrköping) DP Patterning (Norrköping) Epishine (Norrköping/Linköping/Göteborg) Beneli (Helsingborg) Gammleby Screen (Gamleby)

3 Unique collaboration LiU-Acreo Printed Electronics and Bio-electronics! PEA - Printed Electronics Arena Idag 90 forskare

4 PRINTED ELECTRONIC - PRINTABLE CONDUCTING MATERIAL Conducting plastics Nobel Price in Chemistry 2000 Heeger, MacDiarmid och Shirakawa

Challenge PEA - Printed Electronics Arena Traditional Si based electronics too expensive to make low cost Electronics Printed Electronics is too

5 Challenge PEA - Printed Electronics Arena Traditional Si based electronics too expensive to make low cost Electronics Printed Electronics is too low functionality to make demanding low cost applications State of the art silicon chips have 10 7 times higher density than printed electronics

6 PEA - Printed Electronics Arena Hybride solution Cost of Si dominates If the chip size could be reduced the cost could be brought down to a level which can be accepted by the market RFID is the lower limit (around 10 US cent),

7 PEA - Printed Electronics Arena Objective: Provide a open facility that lower the threshold for enterprises to enter into manufacturing of printed electronics and bioelectronics

Printed Electronics Arena Pilot production Dry Phase Patterning metal foils, antennas R2R label printer displays and circuits Slot die coater Photovoltaics ATMA OE

8 Printed Electronics Arena Pilot production Dry Phase Patterning metal foils, antennas R2R label printer displays and circuits Slot die coater Photovoltaics ATMA OE MF66 Aut. sheet based screen printer Laser ablation Screen-printer Ceradrop Inkjet, aerosoljet Novacentrix Xwnon flash Besi Datacon Flip chip Bonder - Pick and place

9 EXEMPEL PÅ ANVÄNDNINGSOMRÅDEN Biosensor för diagnostik i hemmet Smarta förpackningar med temperaturövervakning minskar matslöseriet Batteritestare Smartcard med display

10 PEA - Printed Electronics Arena Thinfilm electronics Leading US Funds Invest USD 22 million in Thinfilm Thinfilm Announces Partnership with Xerox for Mass Production of Thinfilm Memory Labels Thinfilm and G World Unveil First Smart Wine Bottle Powered by Printed Electronics

11 PEA - Printed Electronics Arena Thinfilm electronics TFE License Acreo s display technology that has been developed in PEA Manufacturing TFE and Acreo develop TFT circuitry in a Euostar project utilizing PEA Manufacturing TFE utilised PEA-M for development, before scaling up their on operations TFE hire personel from Acreo and Linköping university

12 PEA - Printed Electronics Arena The Paper Display based on PEDOT Includes a flexible and clearly visible electrochromic display (Developed and produced by Acreo Swedish ICT at PEA manufacturing)with the same accuracy as a battery tester worth hundreds of dollars

13 Dry Phase Patterning Revolutionizing electronic circuitry manufacturing

14 PEA - Printed Electronics Arena

15 DPP METHOD Clean process No chemicals used Environmentally friendly Low production cost Dry process Recyclable residue material

16 PEA - Printed Electronics Arena Printed Humidity Sensors on Labels Measure inside/through the wall Wireless reading Non-destructive Thin and flexible labels Low cost Passive no battery

17 In Control of Moisture

18 PEA - Printed Electronics Arena CONNECTED ME COMMUNICATION BY CAPACITIVE COUPLING body signal Today conventional electronics Next step printed labels

19 HYBRID TRANSMITTER LABELS FOR BODY COUPLED COMMUNICATION Sheet printing: Capacitive antenna Interconnect (Display) Assembly Chips Printed Battery

plattform Multipla sensorer Trådlös kommunikation Printed

21 Biosensorplattform PEA - Printed Electronics Arena Tryckt diagnostikinstrument Låg kostnad Engångstest Generisk sensor plattform Multipla sensorer Trådlös kommunikation Printed Display Sensors Printed Battery Push Button Chip for communication Chip for sensing

22 PEA Open PEA - Printed Electronics Arena

23 Temperature label for vaccines

24 TEMPERATURE LABEL FOR VACCINES

25 PEA - Printed Electronics Arena Vad ser du? Vi ser hur teknik kan hjälpa människor. I vår unika produktionsmiljö PEA Manufacturing hjälper vi dagligen företag att utveckla produkter. Vi kan skapa sensorer, kommunikation, miniatyrisering, nya material och hela elektroniska system i gränssnittet mellan maskin och människa. Tryckt elektronik ger tekniska fördelar och möjligheter att skapa helt nya former. Kom till oss med ditt problem eller din briljanta idé! info@printedelectronicsarena.com
