7 Central user registry As a post-installation task you can configure a central user registry for user management and authentication. You can configure an LDAP server or Tivoli Netcool/OMNIbus ObjectServer registry (or both). In a network environment that includes a user registry on an LDAP server or Tivoli Netcool/OMNIbus ObjectServer, you can configure Tivoli Integrated Portal to use either or both types. In fact, these functions require a central user registry: v v Load balancing, which requires that each Tivoli Integrated Portal server instance in the cluster use the same central user repository, whether that be anldap server or an ObjectServer. Single sign-on, which authenticates users at the central repository during login and whenever they launch into other authorized Tivoli applications. The installer provides for configuration of the IBM Tivoli Directory Server Version 6 and above. If your LDAP server is different, you will need to bypass the selection of LDAP during installation, and configure it through the administrative console afterwards. Before configuring a central user registry, be sure that the user registry or registries that you plan to identify are started and can be accessed from the computer where you have installed the Tivoli Integrated Portal. Adding an external LDAP repository After installation, you can add an IBM Tivoli Directory Server or Active Directory Microsoft Active Directory Server as an LDAP repository for Tivoli Integrated Portal. About this task To add a new LDAP repository: 1. Log in to the Tivoli Integrated Portal. 2. In the navigation pane, click Settings Websphere Admin Console and click Launch Websphere Admin Console. 3. In the WebSphere Application Server administrative console, select Settings Global security. 4. From the Available realm definitions list, select Federated repositories and click Configure. 5. In the Related Items area, click the Manage repositories link and then click Add to add a new LDAP repository. 6. In the Repository identifier field, provide a unique identifier for the repository. The identifier uniquely identifies the repository within the cell, for example, LDAP1. 7. From the Directory type list, select the type of LDAP server. The type of LDAP server determines the default filters that are used by WebSphere Application Server. Copyright IBM Corp

8 Note: IBM Tivoli Directory Server users can choose either IBM Tivoli Directory Server or SecureWay as the directory type. For better performance, use the IBM Tivoli Directory Server directory type. 8. In the Primary host name field, enter the fully qualified host name of the primary LDAP server. The primary host name and the distinguished name must contain no spaces. You can enter either the IP address or the domain name system (DNS) name. 9. In the Port field, enter the server port of the LDAP directory in the Port field. The host name and the port number represent the realm for this LDAP server in a mixed version nodes cell. If servers in different cells are communicating with each other using Lightweight Third Party Authentication (LTPA) tokens, these realms must match exactly in all the cells. Note: The default port value is 389, which is not a Secure Sockets Layer (SSL) connection port. Use port 636 for a Secure Sockets Layer (SSL) connection. For some LDAP servers, you can specify a different port. If you do not know the port to use, contact your LDAP server administrator. 10. Optional: In the Bind distinguished name and Bind password fields, enter the bind distinguished name (DN) (for example, cn=root) and password. Note: The bind DN is required for write operations or to obtain user and group information if anonymous binds are not possible on the LDAP server. In most cases, a bind DN and bind password are needed, except when an anonymous bind can satisfy all of the required functions. Therefore, if the LDAP server is set up to use anonymous binds, leave these fields blank. 11. Optional: In the Login properties field, enter the property names used to log into the WebSphere Application Server. This field takes multiple login properties, delimited by a semicolon (;). For example, cn. 12. Optional: From the Certificate mapping list, select your preferred certificate map mode. You can use the X.590 certificates for user authentication when LDAP is selected as the repository. Note: The Certificate mapping field is used to indicate whether to map the X.509 certificates into an LDAP directory user by EXACT_DN or CERTIFICATE_FILTER. If you select EXACT_DN, the DN in the certificate must match the user entry in the LDAP server, including case and spaces. 13. Click OK. 14. In the Messages area at the top of the Global security page, click the Save link and log out of the WebSphere Application Server console. What to do next Configure the Tivoli Integrated Portal Server to communicate with an external LDAP repository. 2 IBM Tivoli Tivoli Integrated Portal Central user registries

9 Configuring an external LDAP repository You can configure the Tivoli Integrated Portal Server to communicate with an external LDAP repository. About this task In a load balanced environment, all Tivoli Integrated Portal Server instances must be configured separately for the LDAP server. To configure an application server to communicate with an external LDAP repository: 1. Log in to the Tivoli Integrated Portal. 2. In the navigation pane, click Settings Websphere Admin Console and click Launch Websphere Admin Console. 3. In the WebSphere Application Server administrative console, select Settings Global security. 4. From the Available realm definitions list, select Federated repositories and click Configure. 5. To add an entry to the base realm: a. Click Add Base entry to Realm. b. Enter the distinguished name (DN) of a base entry that uniquely identifies this set of entries in the realm. This base entry must uniquely identify the external repository in the realm. Note: If multiple repositories are included in the realm, use the DN field to define an additional distinguished name that uniquely identifies this set of entries within the realm. For example, repositories LDAP1 and LDAP2 might both use o=ibm,c=us as the base entry in the repository. So o=ibm,c=us is used for LDAP1 and o=ibm2,c=us for LDAP2. The specified DN in this field maps to the LDAP DN of the base entry within the repository (such as o=ibm,c=us b). The base entry indicates the starting point for searches in this LDAP directory server (such as o=ibm,c=us c). c. Click OK. d. In the Messages area at the top of the Global security page, click the Save link and log out of the WebSphere Application Server console. 6. In the WebSphere Application Server administrative console, select Settings Global security. 7. From the Available realm definitions list, select Federated repositories and click Set as current to mark the federated repository as the current realm. 8. Stop and restart the Tivoli Integrated Portal Server: a. From the install_dir/profiles/tipprofile/bin directory, enter: stopserver server1 -username myname -password mypassword (where myname is a user name with administrator privileges on the computer and mypassword is the password) b. From the install_dir/profiles/tipprofile/bin directory, enter: startserver server1 9. Verify that the federated repository is correctly configured: a. In the administrative console navigation pane, click Users and Groups Manage Users. b. Select User ID from the Search by list. c. Click Search to search for users in the federated repository. Central user registry 3

10 d. Confirm that the list includes users from both the LDAP repository and the local file registry. On the Tivoli Integrated Portal Server, LDAP users are queried only by the userid attribute. When users are imported into LDAP using an LDAP Data Interchange Format (LDIF) file, an auxiliary class of type eperson and an uid attribute is added to the LDAP user ID. Note that this is to be done only if you want to search the LDAP repository using VMM from the server. What to do next To be able to create or manage users in the administrative console that are defined in your LDAP repository, in the WebSphere Application Server administrative console, you must specify the supported entity types. Managing LDAP users in the console To create or manage users in the administrative console that are defined in your LDAP repository, in the WebSphere Application Server administrative console specify the supported entity types. About this task To create or manage LDAP users in the administrative console: 1. Log in to the Tivoli Integrated Portal. 2. In the navigation pane, click Settings Websphere Admin Console and click Launch Websphere Admin Console. 3. In the WebSphere Application Server administrative console, select Settings Global security. 4. From the Available realm definitions list, select Federated repositories and click Configure. 5. In the Additional Properties area, click Supported entity types. 6. In the Entity type column, click the Group link to display its properties page. 7. In the Base entry for the default parent field, provide a base entry relevant to your LDAP configuration, for example, o=ibm,c=us. 8. In the Relative Distinguished Name properties field, provide the same value that you did for the Base entry for the default parent field, for example, o=ibm,c=us. 9. Click OK to return to the Supported entity types page. 10. Edit the OrgContainer and the PersonAccount entities with the same values that you provided for the Group entity (for example, o=ibm,c=us). 11. In the Messages area at the top of the Global security page, click the Save link and log out of the WebSphere Application Server console. 12. For the changes to take effect, stop, and restart the Tivoli Integrated Portal Server. In a load balanced environment, you must stop and restart each Tivoli Integrated Portal Server instance. Results You can now manage your LDAP repository users in the administrative console through the Users and Groups Manage Users menu items. 4 IBM Tivoli Tivoli Integrated Portal Central user registries

11 Configuring an SSL connection to an LDAP server If your implementation of Tivoli Integrated Portal uses an external LDAP-based user repository, such as Microsoft Active Directory, you can configure it to communicate over a secure SSL channel. Before you begin This task assumes that you have already an existing connection to an LDAP server set up. Your LDAP server (for example, an IBM Tivoli Directory Server Version 6 or an Microsoft Active Directory server), must be configured to accept SSL connections and be running on secured port number (636). Refer to your LDAP server documentation if you need to create a signer certificate, which as part of this task, must be imported from your LDAP server into the trust store of the Tivoli Integrated Portal Server. About this task Follow these instructions to configure the Tivoli Integrated Portal Server to communicate over a secure (SSL) channel with an external LDAP repository. All application server instances must be configured for the LDAP server. 1. Log in to the administrative console. 2. Follow these steps to import your LDAP server's signer certificate into the application server trust store. a. In the navigation pane, click Security SSL certificate and key management. b. In the Related Items area, click the Key stores and certificates link and in the table click the NodeDefaultTrustStore link. c. In the Additional Properties area, click the Signer certificates link and click theretrieve from port button. d. In the relevant fields, provide hostname, port (normally 636 for SSL connections), SSL configuration details, as well as the alias of the certificate for your LDAP server and click the Retrieve signer information button and then click OK. 3. Follow these steps to enable SSL communications to your LDAP server: a. In the navigation pane, click Security Secure administration, applications, and infrastructure. b. Select Federated repositories from the Available realm definitions drop down list and click Configure. a. Select your LDAP server from the Repository drop down list. b. Enable the Require SSL communications check box and the select the Centrally managed option. c. Click OK. 4. For the changes to take effect, save, stop, and restart all Tivoli Integrated Portal Server instances. What to do next If you intend to enable single sign-on (SSO) so that users can log in once and then traverse to other applications without having to re-authenticate, configure SSO. Central user registry 5

12 Configuring an SSL connection to the ObjectServer For environments that include a Tivoli Netcool/OMNIbus ObjectServer user registry, you need to set up encrypted communications on the Tivoli Integrated Portal Server. About this task Follow these steps to establish a secure channel for communications between the Tivoli Integrated Portal Server and the ObjectServer. 1. Retrieve the ObjectServer certificate information, as follows: a. In the Tivoli Integrated Portal navigation pane, click Security SSL certificate and key management. b. On the SSL certificate and key management page, click Key stores and certificates and on the page that is displayed, click NodeDefaultTrustStore. c. On the NodeDefaultTrustStore page, click Signer certificates and on the page that is displayed, click Retrieve from port. d. In the relevant fields, enter Host, Port, and Alias values for the ObjectServer and click Retrieve signer information. The signer information is retrieved and stored. For your reference, when the signer information has been retrieved, the following details are displayed: Serial number Specifies the certificate serial number that is generated by the issuer of the certificate. Issued to Specifies the distinguished name of the entity to which the certificate was issued. Issued by Specifies the distinguished name of the entity that issued the certificate. This name is the same as the issued-to distinguished name when the signer certificate is self-signed. Fingerprint (SHA digest) Specifies the Secure Hash Algorithm (SHA hash) of the certificate, which can be used to verify the certificate's hash at another location, such as the client side of a connection. Validity period Specifies the expiration date of the retrieved signer certificate for validation purposes. 2. Open install_dir/profiles/tipprofile/etc/ com.sybase.jdbc3.sybdriver.props in a text editor and change these parameters: a. Enable SSL for ObjectServer primary host: USESSLPRIMARY=TRUE b. Enable SSL for ObjectServer backup host: USESSLBACKUP=TRUE 3. Stop and restart the Tivoli Integrated Portal Server: a. From the install_dir/profiles/tipprofile/bin directory, enter: stopserver server1 -username myname -password mypassword (where myname is a user name with administrator privileges on the computer and mypassword is the password) b. From the install_dir/profiles/tipprofile/bin directory, enter: startserver server1 6 IBM Tivoli Tivoli Integrated Portal Central user registries
