1 The leading provider for energy efficient, safe and secure buildings and building infrastructure Peter Hallberg BT Nordic Division April 2011 Siemens AG All rights reserved.

2 Who we are and what we do BT is the leading company in the building infrastructure market to offer customers and partners innovative, cost effective and integrated solutions. Peter Hallberg Head of Nordic Division, Siemens Industry Sector Page 2 April 2011 BT helps to protect people and makes buildings and building infrastructure more secure and safe, more comfortable and more efficient throughout their entire lifecycle.

3 What influences the market? Growing of population Urbanization Care for the environment Scarcity of resources By 2025: World population will grow from more than 6 billion now to 8 billion. By 2030: 60% of the world's population will live in cities. Today we face the highest CO 2 concentration for the past 350,000 years. CO2 50% of the world s population consume 75% of the energy. The need of protection of critical infrastructure is increasing. The requirements concerning the security of life and property are constantly increasing. The consumption of energy and the CO 2 -emissions have to be reduced dramatically. Ideal working and living conditions are nevertheless required. Page 3 April 2011

4 What does that mean for our customers? Conclusion drawn from the megatrends and the developments in the market: Building and building infrastructure owner and user have two main 1needs: Safety and security for their buildings and building infrastructure 2 High level of energy efficiency Either as an integrated or as a specific solution Page 4 April 2011 Copyright Siemens Siemens AB AG Alla rättigheter All rights förbehålles. reserved.

5 Siemens Sverige Industry Sektorer Energy Healthcare Divisioner Divisioner Divisioner Drive Technologies Industry Automation Mobility Lighting (OSRAM) Industry Solutions Fossil Power Generation Renewable Energy Oil & Gas Energy Service Power Transmission Power Distribution Imaging & IT Workflow & Solutions Diagnostics Order: MSEK Omsättning: MSEK Investeringar: 878 MSEK Anställda: ~4 900 p Page 5 April 2011

6 What we offer our customers Technologies: Building Automation Services: Life Cycle Services Security System Integration Fire Safety Monitoring Services Power supply and installation equipment Energy Efficiency Solutions Page 6 April 2011

7 Example Danger Management 2c Fire brigade is advised 1 Smoke is detected, dampers are activated 3 Detailed information (location, type of fire, toxic gases, temperature, etc.) about emergency incident is sent to fire brigades for best preparation on mission 2a 2b Elevators are automatically deactivated People are safely guided by voice, displays and lights to the stairs 4 Detailed information about people remaining in the building is available to the fire brigade 6 System delivers detailed information for post incident analysis 5 People are directed to the appropriate and safe exits Page 7 April 2011

8 Example Energy Management Solar panels Energy Management Load management within the building in order to avoid peaks BMS BAS* Energy trading Lighting natural/artificial Electricity storage in the building E-car as temporary power storage Grid Heating, Cooling, Air-Conditioning Thermal energy storage in the building * BEMS: Building Energy Management System BAS: Building Automation Copyright System Siemens AB Alla rättigheter förbehålles. Page 8 April 2011

9 Några svåra frågor som fastighetsägare och fastighetsförvaltare ställs inför Hurdesignarvi Green Buildings? Hur ser vår nuvarande situation ut när det gäller energieffektivitet? Hur finansierar vi projekt för energieffektivetet? Vilka möjliga åtgärder / koncept finns för högre effektivitet? Hur kan vi minimera våra projektrisker? Hur upprätthåller vi optimal effektivitet under hela byggnadens livslängd? Page 9 April 2011

10 Klimatförändringar och global uppvärmning Inte en ny fråga, men nu med rätt fokus! Ingen miljömedvetenhet utan ekonomiska fördelar z z z z z z z z z z z z z zz z Page 10 April 2011

11 Möjligheter till energibesparing I varje byggnad i varje verksamhet Sjukhus Skola Hyreshus % % 20 % Hotell % Butik/galleria % Kontor % Page 11 April 2011

12 Smarta byggnader? Overstretched grids More transparency for consumption/ cost Millions of e-cars Page 12 April 2011

13 Smarta byggnader? - Energieffektiva - Styrbara utifrån elnätets prissignaler - Laddinfrastruktur för elfordon - Småskalig produktion - Energilagringsmöjligheter Overstretched grids - Aktiva konsumenter - Visualisering More transparency for consumption/ cost Millions of e-cars - Möjliga att integreras i överliggande DMS-system Page 13 April 2011

14 Our customer s world is in transformation Consumption will follow load Before Afterwards power information Page 14 April 2011

15 B I From individual subsystems to integrated building management and to smart building within smart grid Disparate Building Controls Functional Controllers HVAC Control Fire detection Access control Building Management & Control Security & Fire Systems Building Automation Energy Management Systems Integration Home Automation Security Convergence Green Buildings IT Convergence Intelligent Buildings Intelligent Green Buildings Integrated Networking Enhanced Management Smart Buildings Energy Control Smart Towns The need for cross-linking disciplines and the need for constant availability of building data affects the growing together of building automation, safety and security systems as well as the IT technology. Source: Frost & Sullivan Page 15 April 2011

16 Example 'Smart Building in a Smart Grid' Low energy costs Fast Charging Water tank PV PV E-Car CHP Electrical storage Thermal storage CHP Electrical storage Thermal storage $ $ Smart Grid Page 16 April 2011

17 Example 'Smart Building in a Smart Grid' High energy costs Fast Charging Water tank PV PV CHP Electrical storage Thermal storage E-Car CHP Electrical storage Thermal storage $$ $$ Smart Grid Page 17 April 2011

18 Drivkrafter för ett smart nät Internationellt - Miljö- och klimatproblematik - Kraftigt åldrad nätinfrastruktur - Leveranssäkerhet - Stora investeringar - Integration av förnyelsebar elproduktion - Balansreglering av intermittent produktion - Massintroduktion av elbilar - Ökad elanvändning - Aktivare konsumenter med vilja att agera prosumers Sverige - Miljö- och klimatproblematik ( målen) - Åldrad nätinfrastruktur (Stämmer delvis) - Leveranssäkerhet (Ej problem) - Integration av förnyelsebar elproduktion - Balansreglering (Ej stort problem) - Massintroduktion av elbilar - Ökad elanvändning (svag ökning) - Aktivare konsumenter med vilja att agera prosumers Page 18 April 2011

19 Our smart grid portfolio Smart consumption Building Management System Building Energy Management System (BEMS) Demand response Energy services for buildings Smart metering solutions Page 19 April 2011

20 Questions and answers Page 20 April 2011

21 Thank You for your attention
